| 轴承型号 Basic Bearing No. | 孔径 Bore d mm inch | 外径 Outerdiameter D mm inch | 宽度 Width W mm inch | 倒角 Radius R min mm inch | 额定负荷 Basic Load Rating KN | 钢球参数 Ball Complement | 极限转数 Max Runout speed | 重量 Weight kg | |||
| Dynamic C | Static Co | No | Size mm | Grease r/min | Oil r/min | ||||||
| 6000 Series | |||||||||||
| 6000 | 10 .3937 | 26 1.0236 | 8 .3150 | 0.3 .012 | 4.58 | 1.98 | 7 | 4.763 | 20000 | 28000 | 0.019 |
| 6001 | 12 .4724 | 28 1.1024 | 8 .3150 | 0.3 .012 | 5.10 | 2.38 | 8 | 4.763 | 19000 | 26000 | 0.021 |
| 6002 | 15 .5906 | 32 1.2598 | 9 .3543 | 0.3 .012 | 5.58 | 2.85 | 9 | 4.763 | 18000 | 24000 | 0.030 |
| 6003 | 17 .6693 | 35 1.3780 | 10 .3937 | 0.3 .012 | 6.00 | 3.25 | 10 | 4.763 | 17000 | 22000 | 0.039 |
