| 轴承型号 Basic Bearing No. | 孔径 Bore d mm inch | 外径 Outerdiameter D mm inch | 宽度 Width W mm inch | 倒角 Radius R min mm inch | 额定负荷 Basic Load Rating KN | 钢球参数 Ball Complement | 极限转数 Max Runout speed | 重量 Weight kg | |||
| Dynamic C | Static Co | No | Size mm | Grease r/min | Oil r/min | ||||||
| 6200 Series | |||||||||||
| 6200 | 10 .3937 | 30 1.1811 | 9 .3543 | 0.6 .024 | 5.10 | 2.38 | 8 | 4.763 | 19000 | 26000 | 0.032 |
| 6201 | 12 .4724 | 32 1.2598 | 10 .3937 | 0.6 .024 | 6.82 | 3.05 | 7 | 5.953 | 18000 | 24000 | 0.037 |
| 6202 | 15 .5906 | 35 1.3780 | 11 .4331 | 0.6 .024 | 7.65 | 3.72 | 8 | 5.953 | 17000 | 22000 | 0.045 |
